Basic Information
|
| Substrate | Coating Content | Function
| Lifespan |
| Titanium (Ta1, Ta2) | Ir, Ta, X | Oxygen Evolution | As Required |
| Electrochemical Performance(Test condition: 1MOL H2SO4,40000A/M2) |
| Chlorine Evolution Potential | Polarizability | Accelerated Life Time | Accelerated Weightlessness |
| < 1.6V | < 40mV | > 750 Hours | 10mg
|
1, Application Area:
Electrolytic copper foil.
Organic electrolytic synthesis.
Chromium plating.
Electro-Oxidtion of wastewater.
Cathodic protection.
Electro-dialysis/ deionization.
Metal recovery.
2, Service Scope:
a, Produce new-made anode/ cathode as per customers' design.
b, Produce electrode assembly as per customers' design.
c, Re-coating old electrodes.
d, Advice suitable electrode with best coating choice.
3, Electrochemical principles:
The ions in the electrolyte are often in disorderly movement. After direct current is applied, the ions move in a directional motion. The cation moves to the cathode and gets electrons at the cathode and is reduced; the anion moves to the anode, loses electrons at the anode and is oxidized.Generally, all copper foil manufacturers dissolve electrolytic copper or waste copper wire with the same purity as electrolytic copper used as the raw material, in sulfuric acid to produce an aqueous solution of copper sulfate. With a Ta-Ir anode, the oxygen will be evoluted at anode side, and copper or other cations will be evoluted at cathode side.
4.Price and after-sales service
Tengyu anode have obvious performance-price ratio advantages and we track each sold products covering the full service time.
